GT STEEL HOOP BULLBAR - FORD PX RANGER

Designed in Sydney Australia, Rockarmor’s design & engineering team left no stone unturned, making sure the PX Ranger GT bull bar would cater for the true 4x4 enthusiasts.

With its harmonious blend of commanding aesthetics and refined details, the ADR Approved bull bar is guaranteed to captivate fellow automotive enthusiasts, while Rockarmor's expert engineers have seamlessly incorporated a comprehensive range of essential features that enhance the driving experience for all PX2 & PX3 Ford Ranger & Wildtrak owners, regardless of the terrain or challenges they may face.

Suits: PX2 Ranger & PX3 Ranger

PLEASE NOTE PX1 WILL REQUIRE SMALL MODIFICATION

FITTING VIDEO BELOW

Features & Specifications:

• Built in 3.2Tonne Rated Recovery Points (Each recovery point) *Soft Shackle Compatible)
• 51mm Top cross tube for maximum frontal protection
• Durable 2.8mm High Quality steel construction for maximum protection
• Designed for high approach angles (great for off-road)
• Built in LED FOG lights & LED Indicator, compatible with factory controls
• Extended Silver Centre Bash Plate (Protects Front)
• ADR Complied Air bag compatible mounting system
• Factory Sensor Compatible
• Side under Protection panels Included
• Twin Slotted Antenna Mounts located on top Cross Tube
• Twin Hi-Lift jack points
• Front Protection Buffers
• Accommodation for a Electric Winch up to 12,000 pound (Built in winch plate)
• Laser cut mounting Holes to accommodate for driving lights (Ability to mount 2 x 9" LED Driving Lights)
• Shot blasted, Chemical Washed (for extra protection against rust) Finished off in a high quality black powder coat finish


THE ROCKARMOR GT BULL BAR

Designed locally in Australia, Rockarmor's all new GT Bull Bar comes with a whole new look, suited towards today's late model vehicles,  that require maximum protection, while complementing your vehicle's factory aesthetics.

As well as offering your truck with maximum frontal protection, The Rockarmor GT bull bar has been designed to improve your Mazda's off road experience with a number of features that include, higher approach angles, facilities for off road recoveries, and provisions for vital accessories that includes, electric winches, driving lights & uhf communication.

The full bumper replacement Steel bull bar comes packed with a number of beneficial features, which include 51mm Tubing, twin slotted antenna mounts, bash plates, Led Fog lights & Indicators, as well as provisions for high lift jack use, winch and driving lights & and Rockarmor all new soft shackle friendly rated recovery points.

The Rockarmor GT Bull Bar, has been engineered to be compatible with your vehicle safety features which include factory air bags & bumper sensors.

The bull bar is finished in a highly durable black powder coat finish, Optional colour matching is available through your local Rockarmor Distributor.

INSTALLATION

To comply with NZTA all daytime running lights should be installed separately to your headlights. Also note that the fog lights need to be adjusted to three degrees down.

If your vehicle's suspension is not upgraded to withstand 60-100kgs, we do recommend that you upgrade the suspension, especially in the front of the vehicle to withstand the weight of the Steel Bumper & optional winch (if an electric winch is installed with the bull bar) If your vehicle's suspension is not upgraded, or if you are running factory suspension, your front suspension will sag and the ride will become bumpy which can possibly lead to further damage.

We recommend when fitting the bull bar to leave a minimum 10-15mm gap between the bullbar and body of the vehicle. This will allow for movement where the chassis & body move independently.

FITTING VIDEO

FITMENT GUIDE
